Brand Name : | VEGOO |
Model Number : | VG-P1.953-32scan |
Certification : | CE ROHC FCC |
Price : | Negotiable |
Payment Terms : | T/T |
Supply Ability : | 8000sqm per month |
Delivery Time : | 15-25days |
Environment-friendly structures of maintenance that is designed for all-purpose installation sites.
Modules,power and system parts are connected through hard connecting interface,convenient to connect and use
High-precision die-cast aluminum cabinets with space between them not large than 0.1mm.
One of the highlights of R-series include protability,rich transformation.Cabinets can be suspended in parallel,arranged horizonally in a curved angle,and mounted in stories.
Features:
About us:
Technical Parmeters
Unit Module | Item | Parameter | |
Model Number | VG-P1.953-32scan | ||
Module Size | 250mm*250mm | ||
Physical Pitch | 1.953mm | ||
Physical Density | 262144 dots/m2 | ||
Pixel Configuration | 1R1G1B | ||
LED Package Mode | SMD 3IN1-1515 | ||
Module Resolution | 128dots(W)*128dots(H) | ||
Max Power Consumption | 40W | ||
Module Thickness | 16mm | ||
Module Weight | 560g | ||
Drive Type | 恒流驱动 Constant Drive | ||
Scan Mode | 1/32 扫描 1/32scan | ||
Port Type | 自定义 Customize | ||
Match Cabinet Size | W500mm*H500mm W500mm*1000mm |
Display Parameters | Dimension | 250mm*250mm |
Thickness | 84mm | |
Weight | 76.5kg | |
Monomer Module Number | 4pcs | |
Maintenance Connection Mode | Pre Maintenance | |
Pixel Per Cabinet | 65536 pixels | |
Best Viewing Angle | H:140° ;V:140° | |
Recommended Viewing | 2m-12m | |
Driver IC | ICND2163 | |
Refresh Rate | 3920Hz | |
Brightness Of White Balance | 700cd/㎡ | |
Operating Temperature/Humidity | -30℃ ~ +60℃ | |
Life Time | >100000 hours | |
Bad Light Rate | <0.0001 | |
MTBF | >5000 hours | |
Cabinet Matching Module Size | 250mmx250mm | |
Cabinet Matching Module Model | P1.953/P2.604/P2.976/ P3.91/P4.81 | |
Power | Input Voltage | 110-220V;AC±10% |
Power Supply | 5V/60A*3 pcs | |
Working Voltage | AC220V±10% | |
Average Power Consumption | 350w/㎡ | |
Max. Power Consumption | 800w/㎡ | |
Control System | CPU | Pentium4 or Above |
Operation System | WIN98/2000/NT/XP/WIN7 | |
Control Method | Synchronization |
